Savaria Orion

• Optional Configurations: Type 1, 2, 3 and 4
• Platform Sizes:
  • W48'' x L54'' x H84'' (1219 mm x 1371 mm x 2134 mm), Type 1, 2, 3, 4
  • W42'' x L60'' x H84'' (1067 mm x 1524 mm x 2134 mm), Type 1, 2, 3, 4
  • W51'' x L51'' x H84'' (1295 mm x 1295 mm x 2134 mm), Type 1, 2, 3, 4
  • W54'' x L54'' x H84'' (1371 mm x 1371 mm x 2134 mm), Type 1, 2, 3, 4 (This size is not LU/LA Compliant)
• Optional Cab Finishes: Choose from architectural white or black steel with plastic laminate overlays
• Optional Fixture Finishes: Brass
• Other Options: Up to 4 stops, hands-free phone, telephone cabinet with choice of finish, manual or automatic fire-rated folding gate, two-speed steel doors with infrared door closing sensors in black, architectural white or stainless steel, fire rated landing doors, overspeed governor, fire recall service, pro-manual or auto swing doors, buffer springs.

• Applications: Commercial (LU/LA), residential, indoors
• Capacity: 1400 lb (635 kg)
• Speed: 30 ft/min (0.15 m/s)
• Maximum travel: 300″ (25', 7.6 m), with up to 6 stops
• Drive/Motor: 1:2 cable hydraulic drive, 5 hp submersed motor
• Minimum Overhead Clearance: 108″ (2743 mm)
• Minimum Pit: 14″ (355 mm)
• Power Supply: 208 volt, three phase, 60 Hz, 30 amps or 240 volt, single phase, 40 amps, 60 Hz

Links open in a new window, and are located on the manufacturer's website.

• Orion LULA Elevator Brochure
• Orion LULA Elevator Owner's Manual
• Orion LULA Elevator Color Chart
• Orion LULA Elevator Planning Guide
• Architectural Drawings
• Manufacturer's Product Page
• Product Video

Any new elevator sold and installed by Maine Accessibility comes with a 1-year labor warranty. If you have ANY problems with your lift in the first year, we will come fix it free of charge.

If anything happens after the first year, Savaria also includes a 36 months parts warranty on almost everything but batteries. You just pay labor. Please see complete details and exclusions here.
